    DFM100 Self Cleaning Scraper Filter For Mother Liquor Filtration

    Ask Lasest Price
    Brand Name : LIVIC
    Model Number : DFM
    Certification : ISO9001/SGS
    Price : Negotiation
    Payment Terms : T/T, L/C
    Supply Ability : 20pcs per month
    Delivery Time : 60 work days
    • Product Details
    • Company Profile

    DFM100 Self Cleaning Scraper Filter For Mother Liquor Filtration

    Automatic Scraper Filter DFM Series Self-cleaning Filter for Mother Liquor Filtration


    Description


    Scraping self-cleaning filter (DFM filter for short), automatically removes particles from the filter element surface by the efficiently mechanical scraping, can work on-line continuously, consumes no disposal filter media, requires no frequent manual cleaning, is capable of the filtration for both normal and high viscous liquids. DFM series, the motor drives the scraper to rotate and remove the particles on the filter element internal surface. DFM series are good for the high viscous liquid.


    In industrial parts cleaning, DFM filters and filter media ensure compliance with the precisely defined residual dirt and residual particle values for the workpieces by efficiently cleaning the process fluids. At the same time, this protects the expensive systems from contamination, ensures long-term availability of the cleaning media and makes an important contribution to operational safety and environmental protection.


    Specifications:


    Filter Main TypeDFM22DFM41DFM71
    Filter Area(c㎡)0-7140
    Volume(L)0-175
    Filtration Degree100-3000μm
    Design Temperature0-200℃(determined by seal materials)
    D.P. Instrumentpressure transmitter / differential pressure transmitter
    Inlet&Outlet StandardHG20592-2009 Flange(standard, DIN compatible ), HG20615-2009 Flange ( ANSI B16.5 compatible)DIN11851 sanitary coupling, female thread
    Housing Wet Part Material304/316L/CS
    Housing Seal MaterialNBR/ VITON /PTFE

    Applications:


    Applicable industries: Water treatment, pulp and paper, petro-chemical, bio-pharmaceutical, coatings, inks, oil refinery, food and beverage

    Typical applicable liquid: Wax, coal oil, monomer, water, citric acid, fermentation broth, protein, soap, wet end additive, coating, ink, adhesive, rubber, ethanol, chocolate, confectionary, juice, coolant, etc.
