    Automatic Scraper Filter 1.0 MPa 200℃ Self Cleaning For Palm Oil Filtration

    Ask Lasest Price
    Brand Name : LIVIC
    Model Number : DFM
    Certification : ISO9001/SGS
    Price : Negotiation
    Supply Ability : 100pcs per year
    Delivery Time : 60 work days
    • Product Details
    • Company Profile

    Automatic Scraper Filter 1.0 MPa 200℃ Self Cleaning For Palm Oil Filtration

    Automatic Scraper Filter DFM Series Self-cleaning Palm Oil Filtration


    Description


    DFM series scraping self-cleaning filter (DFM filter for short), automatically removes particles from the filter element surface by the efficiently mechanical scraping, can work on-line continuously, consumes no disposal filter media, requires no frequent manual cleaning, is capable of the filtration for both normal and high viscous liquids. DFM series, the motor drives the scraper to rotate and remove the particles on the filter element internal surface. DFM series are good for the high viscous liquid.


    Specifications:


    Filter Main TypeDFM22DFM41DFM71
    Filter Area(c㎡)0-7140
    Volume(L)0-175
    Filtration Degree100-3000μm
    Design Temperature0-200℃(determined by seal materials)
    D.P. Instrumentpressure transmitter / differential pressure transmitter
    Inlet&Outlet StandardHG20592-2009 Flange(standard, DIN compatible ), HG20615-2009 Flange ( ANSI B16.5 compatible)DIN11851 sanitary coupling, female thread
    Housing Wet Part Material304/316L/CS
    Housing Seal MaterialNBR/ VITON /PTFE

    Applications:


    Applicable industries: Water treatment, pulp and paper, petro-chemical, bio-pharmaceutical, coatings, inks, oil refinery, food and beverage

    Typical applicable liquid: Wax, coal oil, monomer, water, citric acid, fermentation broth, protein, soap, wet end additive, coating, ink, adhesive, rubber, ethanol, chocolate, confectionary, juice, coolant, etc.
